Page 00 : Introduction


For the railway enthusiast, China offers a fascinating mix of old and new locomotives, American, Japanese, Soviet and European influences, steam, diesel and electric traction, heavy traffic, stunning landscapes and friendly people.

Until recently, my own visits had been exclusively aimed at capturing working steam on film but in the process I've seen and photographed many diesels of many classes in many places. Coverage is currently far from comprehensive as I've never been to the south and haven't photographed several of the more modern main line classes which were introduced after steam was banished to independent and industrial lines. As steam operation declines, trips, specifically to see modern traction, will become more common and coverage should improve.

This feature describes more than a dozen classes of loco with brief technical details where known, history and operational data. Classes are listed alphabetically.

This version includes several new classes and more will be added as time and availability permit.

Robin Gibbons' Railways of China site is an excellent source of information about Chinese diesel and electric locos and multiple units and is required surfing for those interested in the current rail scene. Thanks are also due to Bruce Evans for providing additional information.


Class
Type
Trans.

Power
(kW)

No.
Built

Page
BJ
B'-B'
Hyd
2000
300+
DF/DF3
Co'-Co'
Elec
1350
960
DF2
Co'-Co'
Elec
790
150
DF4/4A
Co'-Co'
Elec
2430
840+
DF4B
Co'-Co'
Elec
2430
4700+
DF4C
Co'-Co'
Elec
2650
1000+
DF4D
Co'-Co'
Elec
2940
1000+
DF5
Co'-Co'
Elec
1210
1000+
DF7
Co'-Co'
Elec
1470
300+
DF7B
Co'-Co'
Elec
1840
200+
DF7C
Co'-Co'
Elec
1470
1840
650+
DF7D
Co'-Co'
Elec
1840
200+
DF7G
Co'-Co'
Elec
1840
150+
DF8
Co'-Co'
Elec
3310
140
DF8B
Co'-Co'
Elec
3680
700+
DF10
Co'-Co'
Elec
2200
?
DF11
Co'-Co'
Elec
3610
450+
DFH1
B'-B'
Hyd
1350
100+
DFH3
B'-B'
Hyd
2000
300
GKD1
Bo'-Bo'
Elec
990
50+
GKD3B
Co'-Co'
Elec
?
?
ND5
Co'-Co'
Elec
2685
400+
NYJ1
Unit
Elec
1492
?
NZJ1
Unit
Elec
5520
?
NZJ2
Unit
Elec
6620
?

NOTE All the data above should be treated as approximate (except the page numbers, which should be accurate).
